30W Full-color Laser Light
MAIN FEATURES
Laser Configuration: R635-9W/G525-10W/B455-12W
Operating Voltage: AC100~240V, 50/60Hz Power Consumption: ≤850W
Scanning System: High-speed galvanometer scanning mirrors with a maximum optical angle of ±30°. Input signal ±5V, linear distortion <2%
Beam Diameter and Divergence Angle: 8*6.5mm beam diameter with a divergence angle of 1.2mrad
Control Modes: Auto mode, master-slave, DMX512, SD card, Art-Net, ILDA laser software
Control Interfaces: Three-core DMX512 interface, ILDA DB25 interface, EASY ILDA/Art-Net Ethernet interface, SD card
DMX Channels: 27CH/52CH
Demonstration Effects: Built-in 140 patterns (7 groups x 20 patterns) and 20 animations (1 group x 20 animations). SD card with unlimited storage, allowing the selection of scenes or laser shows from the SD card via DMX.
Electronic Control Technology:
1. Two-way transmission of data using RDM.
2. SD card online upgrade capability.
3. Intelligent temperature control system.
4. DMX512 upgrade capability.
DMX Special Effects: Single pattern mode with features like broken pen, strobe, rotation, movement, rolling, split image, gradual painting, color change, and resizing.
Product Description
The high-speed galvanometer scanning system guarantees accurate and dynamic projections, with a maximum optical angle of ±30°. The beam diameter of 8*6.5mm and a divergence angle of 1.2mrad provide sharp and precise laser effects.
Control and customization options are extensive, including auto mode, master-slave operation, DMX512 control, SD card playback, Art-Net compatibility, and ILDA laser software control. The three-core DMX512 interface, ILDA DB25 interface, EASY ILDA/Art-Net Ethernet interface, and SD card allow for easy integration and control.
With an array of built-in patterns and animations, and the ability to store even more on an SD card, the laser light enables mesmerizing visual displays. The DMX special effects further enhance the versatility, allowing for functions like broken pen, strobe, rotation, movement, rolling, split image, gradual painting, color change, and resizing.
The laser light features advanced electronic control technologies, including RDM data transmission, online upgradability via SD card, an intelligent temperature control system, and DMX512 upgradability.
Operating within a temperature range of 0~35°C and in a clean, dust-reduced environment helps to retain optimal laser power and extend the lamp’s lifespan.
Perfect for concerts, sports stadiums, advertising campaigns, electronic music festivals, and live performances, our 30W Full-color Laser Light adds a captivating element to any event, creating stunning visual experiences that will leave a lasting impression on the audience.
